| 1 |
B223 2710 |
Supporter - Left No.2 |
|
|
| 10 |
AA14 3404 |
Stepped Screw - M4 |
|
|
| 11 |
B223 4523 |
Link:Stopper |
|
|
| 12 |
B223 1120 |
Bracket:Paper Feed Unit |
|
|
| 13 |
B223 1245 |
Cap:Grip |
|
|
| 14 |
B223 1101 |
Grip:Front |
|
|
| 15 |
B223 1102 |
Bracket:Grip:Right Front |
|
|
| 16 |
D009 1093 |
Stopper Bracket - Grip |
|
|
| 17 |
B223 2702 |
Heat Sink:Heater:NA |
|
|
| 17 |
B223 2703 |
Heat Sink:Heater:EU |
|
|
| 18 |
D011 1253 |
Decal:Main Switch:On-Standby:EU |
|
|
| 18 |
D011 1252 |
Decal:Main Switch:On-Standby |
|
|
| 19 |
D009 4575 |
Gasket:Duplex Unit |
|
|
| 2 |
D009 5475 |
Interface Harness - BICU-LDB |
|
|
| 20 |
B223 2846 |
Bracket:Cover:Harness |
|
|
| 21 |
B223 2848 |
Cover:Harness |
|
|
| 22 |
D009 8495 |
Heater:Paper Feed:Option:NA:Assy |
|
|
| 22 |
D009 8493 |
Heater:Paper Feed:Option:EU:Assy |
|
|
| 3 |
B223 2715 |
Supporter - Right |
|
|
| 4 |
B223 2714 |
Positioning Cap - Short |
|
|
| 5 |
AA16 1163 |
Cushion |
|
|
| 6 |
B223 4524 |
Wire:Stopper:DIA1.5 |
|
|
| 7 |
B101 1097 |
Rubber Foot:H5 |
|
|
| 8 |
D009 4595 |
Rear Guide - Duplex Unit Set |
|
|
| 9 |
D009 4594 |
Front Guide - Duplex Unit Set |
|
|
