| 1 |
AW01 0118 |
Paper Feed Sensor |
|
|
| 10 |
AE03 1069 |
Rear Bushing - Cleaning Roller |
|
|
| 11 |
AE04 0042 |
Oil Supply Roller |
|
|
| 12 |
AE04 2080 |
Cleaning Roller:Assy |
|
|
| 13 |
D014 4253 |
Front Side Plate - Cleaning Roller |
|
|
| 14 |
AE03 1068 |
Front Bushing - Cleaning Roller |
|
|
| 2 |
5206 2684 |
Shoulder Screw - M3 |
|
|
| 3 |
D014 4258 |
Bracket -paper Feed Sensor |
|
|
| 4 |
D014 4257 |
Guide - Fusing Exit |
|
|
| 5 |
D014 4256 |
Guide Plate - Fusing Exit |
|
|
| 6 |
D014 4250 |
Bracket - Cleaning Roller |
|
|
| 7 |
D014 4255 |
Pickoff Pawl:Pressure Sub-Unit:Sub-Assy |
|
|
| 8 |
D014 4254 |
Rear Side Plate - Cleaning Roller |
|
|
| 9 |
AA06 3991 |
Spring - Oil Supply Roller |
|
|
