| 1 |
B132 6655 |
Stepper Motor:Paper Feed Unit:Assy |
|
|
| 10 |
B132 1367 |
Shaft:Drive:Vacuum |
|
|
| 11 |
AB01 1250 |
Gear:22Z |
|
|
| 12 |
AX06 0362 |
Motor:DC24V 48W |
|
|
| 13 |
AA14 3301 |
Stepped Screw - M3x4 |
|
|
| 14 |
AB03 0770 |
Timing Pulley:47T |
|
|
| 15 |
AB03 0768 |
Timing Pulley:47T |
|
|
| 16 |
D014 1371 |
Gear:80Z/30T |
|
|
| 17 |
AA06 0951 |
Pressure Spring |
|
|
| 18 |
B132 1356 |
Bracket:Tightener:Assy |
|
|
| 19 |
B132 1360 |
Shaft:Drive:Fusing:Assy |
|
|
| 2 |
AA06 0958 |
Tension Spring |
|
|
| 20 |
B132 1370 |
Pulley:Idler |
|
|
| 21 |
AA04 3965 |
Timing Belt:40S3M471 |
|
|
| 22 |
AA04 3964 |
Timing Belt:60S3M741 |
|
|
| 23 |
AB03 0771 |
Timing Pulley:44T |
|
|
| 24 |
AB03 0772 |
Timing Pulley:44T |
|
|
| 25 |
B132 1363 |
Shaft:Drive:Reverse:Assy |
|
|
| 26 |
D014 1380 |
Bracket:Drive:Fusing Unit |
|
|
| 27 |
AB01 1304 |
Gear:40Z |
|
|
| 28 |
AB01 1302 |
Gear:30Z |
|
|
| 29 |
B132 2679 |
Bracket:Gear:Swivel |
|
|
| 3 |
B132 2760 |
Bracket:Drive:Paper Feed Sub-Unit |
|
|
| 30 |
B132 2699 |
Spacer:Mm12 |
|
|
| 31 |
B132 2762 |
Shaft:Drive:Paper Feed |
|
|
| 32 |
AB01 1303 |
Gear:33Z |
|
|
| 4 |
AB03 0301 |
Timing Pulley:35T |
|
|
| 5 |
AA04 3313 |
Timing Belt:40S2M150 |
|
|
| 6 |
AA13 2025 |
Spacer - 1x8x12 |
|
|
| 7 |
A247 2800 |
Ball Bearing - 8x12x5 |
|
|
| 8 |
D014 5373 |
AC/DC Harness - PSU-Fusing 200V |
|
|
| 8 |
D014 5371 |
Harness:PSU:Fusing:100V |
|
|
| 8 |
D014 5374 |
Harness - PSU 230V |
|
|
| 9 |
D014 1372 |
Gear:86Z |
|
|
