| 1 |
B044 1060 |
Scanner Unit Stay |
|
|
| 10 |
B044 1066 |
Ground Plate - Option Tray |
|
|
| 101 |
0450 3008N |
Tapping Screw - M3x8 |
|
|
| 102 |
0954 3008N |
Screw - M3x8 |
|
|
| 103 |
0451 3006N |
Tapping Screw - 3x6 |
|
|
| 104 |
0450 3010N |
Tapping Screw - M3x10 |
|
|
| 105 |
1105 0409 |
Card Spacer- 6.4mm |
|
|
| 106 |
1105 0511 |
Harness Clamp - LWS-0306ZC |
|
|
| 107 |
1105 0522 |
Edge Saddle - LES0510 |
|
|
| 11 |
B044 1105 |
Positioning Plate - Toner Bottle |
|
|
| 12 |
B044 1061 |
Base Bracket |
|
|
| 13 |
B044 1062 |
Base Bracket - Paper Feed |
|
|
| 14 |
B044 2202 |
Mylar - Quenching Lamp |
|
|
| 15 |
B129 1315 |
Separation Bracket |
|
|
| 16 |
B129 1302 |
Power Supply Unit Bracket |
|
|
| 17 |
B044 2617 |
Holder Assy - Paper Dust Removal |
|
|
| 18 |
B044 1998 |
Harness Holder Bracket |
|
|
| 2 |
B262 2623 |
Guide - Paper Dust Remover |
|
|
| 3 |
D067 5235 |
Ground Wire:Cassette |
|
|
| 4 |
B129 1301 |
BICU Shadeing Plate |
|
|
| 5 |
B129 1300 |
BICU Bracket |
|
|
| 6 |
G512 3029 |
Rubber Foot |
|
|
| 7 |
B044 2651 |
Right Rail |
|
|
| 8 |
B044 5300 |
Paper End Sensor |
|
|
| 9 |
B129 1060 |
PSU Stay |
|
|
