Каталог запчастей для Konica-Minolta bizhub C352P - FUSING DRIVE SECTION
| № |
Номер партии |
Описание |
Примечание |
|
|
|
| 1 |
9J06 2556 01 |
BRACKET |
D |
|
| 10 |
4658 3516 01 |
BUSHING |
C |
|
| 11 |
4154 3804 01 |
SCREW |
C |
|
| 12 |
9J06 2557 01 |
HOLDER |
C |
|
| 13 |
9J06 2541 01 |
GEAR 20T |
C |
|
| 14 |
9J06 2574 01 |
GEAR 16T |
C |
|
| 15 |
9J06 2559 01 |
SHAFT |
D |
|
| 16 |
9J06 2101 00 |
BUSHING |
C |
|
| 17 |
9J06 2595 02 |
PRESSURE SPRING |
C |
|
| 18 |
9J06 2546 01 |
GEAR 13T |
C |
|
| 19 |
4038 2580 01 |
GEAR 16T |
C |
|
| 2 |
9J06 2570 01 |
GEAR 28/82T |
C |
|
| 20 |
9J06 2576 03 |
BRACKET |
D |
|
| 21 |
9J06 2575 01 |
GEAR 22T |
C |
|
| 22 |
9J06 2594 01 |
SHAFT |
D |
|
| 23 |
9J06 2587 02 |
SHAFT |
D |
|
| 24 |
9J06 0207 01 |
BRACKET ASSY |
D |
|
| 25 |
9J06 2542 01 |
GEAR 18/75T |
C |
|
| 26 |
9J06 2564 01 |
SHAFT |
D |
|
| 27 |
9J06 2543 01 |
GEAR 60T |
C |
|
| 28 |
9J06 2544 01 |
DETECTING PLATE |
C |
|
| 29 |
4037 0906 01 |
PHOTO INTERRUPTER |
B |
|
| 3 |
9J06 2566 01 |
GEAR 18T |
C |
|
| 30 |
9J06 R726 00 |
MOTOR ASSY |
C |
|
| 31 |
9322 1300 21 |
CLUTCH |
B |
|
| 32 |
9J06 2596 01 |
SHAFT |
D |
|
| 33 |
4038 2592 01 |
GEAR 18T |
C |
|
| 34 |
9J06 2547 01 |
GEAR 35T |
C |
|
| 35 |
4038 2591 01 |
GEAR 18T |
C |
|
| 36 |
4038 2593 02 |
GEAR 41T |
C |
|
| 37 |
9383 2210 11 |
CONNECTOR 2P |
D |
|
| 38 |
9J06 2545 01 |
GEAR 40T |
C |
|
| 39 |
9J06 2563 02 |
SHAFT |
D |
|
| 4 |
9J06 2585 01 |
PRESSURE SPRING |
C |
|
| 40 |
4038 M101 00 |
MOTOR |
B |
|
| 41 |
9J06 2548 00 |
PLATE |
C |
|
| 5 |
9J06 2582 01 |
HOLDER |
D |
|
| 6 |
9J06 2584 01 |
LEVER |
C |
|
| 7 |
9J06 2581 01 |
SHAFT |
D |
|
| 8 |
9J06 2571 01 |
GEAR 28T |
C |
|
| 9 |
9J06 2573 01 |
SHAFT |
D |
|
