Каталог запчастей для Konica-Minolta bizhub C252P - MPT CASSETTE TRAY SECTION
| № |
Номер партии |
Описание |
Примечание |
|
|
|
| 1 |
4036 3022 03 |
LIFTING PLATE |
C |
|
| 10 |
1164 3061 01 |
LEVER |
C |
|
| 11 |
1164 3062 01 |
PRESSURE SPRING |
C |
|
| 12 |
4004 3033 01 |
GUIDE PLATE |
D |
|
| 13 |
4004 3038 01 |
GUIDE |
C |
|
| 14 |
4004 3008 01 |
SEAL |
C |
|
| 15 |
4038 7337 01 |
LABEL PAPER SUPPLY |
C |
|
| 16 |
4036 3021 02 |
CASSETTE |
D |
|
| 17 |
4038 3020 03 |
COVER |
D |
|
| 18 |
4038 7321 01 |
LABEL NUMBER |
C |
|
| 19 |
4036 3025 01 |
HANDLE |
C |
|
| 2 |
4687 3281 01 |
FRICTION SHEET |
C |
|
| 20 |
4038 3071 02 |
COVER |
C |
|
| 21 |
4163 5293 01 |
SCREW |
C |
|
| 22 |
4004 3051 02 |
LEVER |
C |
|
| 23 |
4004 3031 01 |
BRACKET |
D |
|
| 24 |
4037 3226 01 |
SPACER |
D |
|
| 25 |
4037 3223 01 |
REGULATING PLATE |
C |
|
| 26 |
4004 3032 01 |
RACK |
C |
|
| 27 |
4021 3036 01 |
GUIDE |
C |
|
| 28 |
4004 3042 01 |
GUIDE |
C |
|
| 29 |
1164 3045 01 |
GEAR 20T |
C |
|
| 3 |
4134 3106 01 |
PRESSURE SPRING |
C |
|
| 30 |
4036 7313 01 |
LABEL MP FD |
D |
|
| 31 |
4039 5604 00 |
RAIL |
D |
|
| 32 |
4037 3227 01 |
SPACER |
D |
|
| 33 |
4004 7324 01 |
LABEL CAPACITY |
C |
|
| 34 |
4036 3028 12 |
REGULATING PLATE |
C |
|
| 35 |
4036 3086 01 |
BRAKE |
D |
|
| 36 |
4036 3019 01 |
LEVER |
D |
|
| 37 |
4030 7301 02 |
LABEL NEAR EMPTY |
C |
|
| 38 |
4038 R734 00 |
MULTIPURPOSE CASSETTE |
S |
|
| 4 |
4036 3008 01 |
REGULATING PLATE |
C |
|
| 5 |
4036 7314 01 |
LABEL MP CD |
D |
|
| 6 |
4038 5601 00 |
PRESSURE SPRING |
C |
|
| 7 |
4037 3210 01 |
LEVER |
C |
|
| 8 |
4004 3040 02 |
GUIDE |
C |
|
| 9 |
4004 3024 01 |
GUIDE |
C |
|
