Каталог запчастей для Konica-Minolta bizhub C250P - ERASER SECTION
| № |
Номер партии |
Описание |
Примечание |
|
|
|
| 1 |
4038 2199 02 |
SHIELD PLATE |
|
|
| 10 |
4038 2072 03 |
PLATE SPRING |
|
|
| 11 |
4038 2198 02 |
SHiELD PLATE |
|
|
| 12 |
4038 2040 01 |
REINFORCE PLATE |
|
|
| 13 |
4038 2056 02 |
SEAL |
|
|
| 14 |
4038 2052 02 |
DUC |
|
|
| 15 |
4038 2053 02 |
SEAL |
|
|
| 16 |
4038 2081 02 |
SEAL |
|
|
| 17 |
4038 2091 03 |
REINFORCE PLATE |
|
|
| 18 |
4038 2012 03 |
BRACKET |
|
|
| 19 |
4038 2151 02 |
SEAL |
|
|
| 2 |
4038 2182 01 |
BRACKET |
|
|
| 20 |
4038 2106 01 |
PIPE |
|
|
| 21 |
4038 2104 02 |
SEAL |
|
|
| 22 |
4038 2103 04 |
SHUTTER |
|
|
| 23 |
4038 2105 03 |
TORSION SPRiNG |
|
|
| 24 |
4038 2102 01 |
SEAL |
|
|
| 25 |
4038 2101 01 |
PIPE |
|
|
| 26 |
4038 2183 01 |
BRACKET |
|
|
| 3 |
4038 2181 01 |
BRACKET |
|
|
| 4 |
9353 2400 11 |
LED PILOT LAMP |
|
|
| 5 |
4038 2015 02 |
BRACKET |
|
|
| 6 |
4038 2014 07 |
RAIL |
|
|
| 7 |
4038 7309 01 |
LABEL |
|
|
| 8 |
4038 2011 03 |
BRACKET |
|
|
| 9 |
4038 2069 01 |
SLIDER |
|
|
