Каталог запчастей для Konica-Minolta bizhub C250 - SCANNER DRIVE SECTION
| № |
Номер партии |
Описание |
Примечание |
|
|
|
| 1 |
4036 1369 01 |
FRAME |
D |
|
| 10 |
4036 1328 01 |
BRACKET |
D |
|
| 11 |
4036 1720 01 |
PRESSURE SPRING |
C |
|
| 12 |
4037 1721 02 |
LEVER |
D |
|
| 13 |
4036 1370 01 |
FRAME |
D |
|
| 14 |
4036 6860 01 |
WIRE HARNESS ASSY |
D |
|
| 15 |
9326 1810 21 |
FERRITE CORE |
D |
|
| 16 |
4036 1371 04 |
REINFORCE PLATE |
D |
|
| 17 |
9313 1300 41 |
FAN MOTOR |
C |
|
| 18 |
4005 1320 01 |
DUMPER |
C |
|
| 19 |
4038 6863 01 |
WIRE HARNESS ASSY |
D |
|
| 2 |
4581 1627 01 |
SEAL |
D |
|
| 20 |
9314 1910 81 |
MOTOR |
C |
|
| 21 |
4002 1471 01 |
CUSHION |
C |
|
| 22 |
4002 1458 01 |
TENSION SPRING |
C |
|
| 23 |
4038 1457 01 |
BRACKET |
D |
|
| 24 |
4038 0115 01 |
PWB ASSY |
I |
|
| 25 |
9384 1900 57 |
PWB SUPPORT 9.53H |
D |
|
| 3 |
4581 1625 01 |
SEAL |
D |
|
| 4 |
4038 1513 01 |
SEAL |
C |
|
| 5 |
4038 1512 01 |
SEAL |
C |
|
| 6 |
4036 1632 02 |
SEAL |
D |
|
| 7 |
4038 1301 01 |
FRAME |
D |
|
| 8 |
4036 1631 01 |
SEAL |
D |
|
| 9 |
4037 0903 01 |
PHOTO INTERRUPTER |
B |
|
