Каталог запчастей для Konica-Minolta bizhub 287 - 2ND PAPER FEED SECTION
| № |
Номер партии |
Описание |
Примечание |
|
|
|
| 1 |
A7AH563700 |
Gear 24/35T |
C |
|
| 10 |
A7AH578200 |
Conveyance Guide |
D |
|
| 11 |
A7AH565301 |
Paper feed Frame |
D |
|
| 12 |
A5C1M50100 |
Photointerrupter |
B |
|
| 13 |
A7AH571100 |
Mounting Plate |
D |
|
| 14 |
A0EDM50100 |
Photoreflector |
I |
|
| 15 |
A7AH565702 |
Conveyance Guide |
D |
|
| 16 |
A7AH560500 |
Shaft /Paper feed |
D |
|
| 17 |
A7AH562400 |
Paper feed Gear |
C |
|
| 18 |
A02E561100 |
Clutch |
C |
|
| 19 |
A00J563600 |
Roller |
A |
|
| 2 |
A7AHM20500 |
Clutch |
C |
|
| 20 |
56AA40490 |
SHAFT STOPPER 4 |
C |
|
| 21 |
A5C1562200 |
Roller |
A |
|
| 22 |
A7AH562600 |
Conveyance Gear 28T |
C |
|
| 23 |
A7AH562300 |
Idling Gear |
C |
|
| 24 |
A7AH563400 |
Support Shaft |
D |
|
| 25 |
A7AH562900 |
Protection Sheet |
C |
|
| 26 |
A7AH562100 |
Conveyance Guide /4 |
D |
|
| 27 |
A7AHN13100 |
Harness /Paperfeed |
D |
|
| 28 |
A7AH569500 |
Protection Seal |
C |
|
| 29 |
A7AH579300 |
Mounting Plate |
D |
|
| 3 |
A7AH563800 |
Shaft |
D |
|
| 30 |
A7AH561601 |
Detecting Lever |
C |
|
| 31 |
A7AH562801 |
Compressing Coil spring |
C |
|
| 4 |
A7AHM20400 |
Clutch |
C |
|
| 5 |
A00J663200 |
Bushing |
C |
|
| 6 |
A7AH579101 |
Mounting Plate |
D |
|
| 7 |
A7AH578100 |
Drive Roller |
C |
|
| 8 |
A7AH578800 |
Torsion Coil spring |
C |
|
| 9 |
A7AH578600 |
Actuator |
C |
|
