Группа запчастей для Samsung ML-2850D_XEV -
| № |
Номер партии |
Описание |
Примечание |
|
|
|
| 5.12-0 |
JC96-04735A |
ELA UNIT-SCF |
|
|
| 5.12-1 |
JC97-03017A |
MEA UNIT-CASSETTE |
|
|
| 5.12-10 |
JC97-03062A |
MEA UNIT-PICK UP |
|
|
| 5.12-10-1 |
JC61-00909A |
HOUSING-M-PICK UP_R2 |
|
|
| 5.12-10-2 |
JC73-00265A |
RUBBER-PICK_UP |
|
|
| 5.12-10-3 |
JC61-00910A |
HOUSING-M-PICK UP2_R2 |
|
|
| 5.12-11 |
JC96-04771A |
ELA HOU-FRAME_SCF |
|
|
| 5.12-11- |
JC72-00975A |
PMO-ACTUATOR EMPTY |
|
|
| 5.12-11-1 |
JC61-02189A |
FRAME-SCF |
|
|
| 5.12-11-1 |
JC33-00026A |
SOLENOID-PICK UP |
|
|
| 5.12-11-10 |
JC61-00836A |
FOOT-FRONT |
|
|
| 5.12-11-11 |
JC63-01609A |
COVER-HARNESS_SCF |
|
|
| 5.12-11-12 |
JC63-00492A |
COVER-M-SIMM R2 |
|
|
| 5.12-11-13 |
JC92-01911A |
PBA-SCF |
|
|
| 5.12-11-14 |
JC63-01636A |
GROUND-PAPER_SCF |
|
|
| 5.12-11-15 |
JC63-01635A |
GROUND-BRUSH_SCF |
|
|
| 5.12-11-17 |
JC61-00587A |
BUSH-M-PICK_UP R |
|
|
| 5.12-11-18 |
JC61-00915A |
STOPPER-M-PICK UP_R2 |
|
|
| 5.12-11-19 |
JC72-00982A |
PMO-IDLE PICK_UP |
|
|
| 5.12-11-2 |
JC63-00369A |
SHEET-COVER SENSOR |
|
|
| 5.12-11-27 |
JC66-00394A |
GEAR-FEED 2 |
|
|
| 5.12-11-29 |
JC72-00980A |
PMO-GEAR PICK_UP B |
|
|
| 5.12-11-3 |
JC70-11028A |
IPR-GROUND TOP |
|
|
| 5.12-11-31 |
6107-001170 |
SPRING-TS |
|
|
| 5.12-11-4 |
6003-000196 |
SCREW-TAPTITE |
|
|
| 5.12-11-5 |
JC72-00983A |
PMO-LOCKER CST |
|
|
| 5.12-11-7 |
JC63-00527A |
SHEET-BRUSH |
|
|
| 5.12-11-8 |
JC75-00095A |
MEC-BRUSH ANTISTATIC |
|
|
| 5.12-11-9 |
JC61-40001A |
FOOT-ML80 |
|
|
| 5.12-2 |
JC63-01607A |
COVER-FRONT_SCF |
|
|
| 5.12-21 |
JC61-00586A |
BUSH-M-PICK_UP L |
|
|
| 5.12-22 |
JC66-01653A |
SHAFT-FEED_SCF |
|
|
| 5.12-23 |
JC66-00598A |
ROLLER-FEED |
|
|
| 5.12-24 |
JC72-00382B |
PMO-BUSHING FEED |
|
|
| 5.12-3 |
JC63-01530A |
COVER-RIGHT_SCF |
|
|
| 5.12-4 |
JC63-01529A |
COVER-LEFT_SCF |
|
|
| 5.12-5 |
JC63-01608A |
COVER-REAR_SCF |
|
|
| 5.12-6 |
JC63-01650A |
COVER-DUPLEX |
|
|
| 5.12-7 |
JC63-01651A |
COVER-REAR DUPLEX |
|
|
| 5.12-8 |
6003-000196 |
SCREW-TAPTITE |
|
|
| 5.12-9 |
JC96-04772A |
ELA HOU-MOTOR_SCF |
|
|
| 5.12-9-1 |
JC61-02228A |
BRACKET-MOTOR_SCF |
|
|
| 5.12-9-10 |
JC72-00825A |
PMO-IMPELLER_DRV |
|
|
| 5.12-9-11 |
6003-000269 |
SCREW-TAPTITE |
|
|
| 5.12-9-12 |
6031-000023 |
WASHER-PLAIN |
|
|
| 5.12-9-2 |
JC61-02234A |
SUPPORT-FEED_SCF |
|
|
| 5.12-9-3 |
JC66-01785A |
GEAR-IDLE 59 |
|
|
| 5.12-9-4 |
JC66-00688A |
GEAR-61/47 IDLE |
|
|
| 5.12-9-5 |
JC66-00396A |
GEAR-IDLE 23 |
|
|
| 5.12-9-6 |
JC66-00690A |
GEAR-35 IDLE |
|
|
| 5.12-9-7 |
JC66-01784A |
GEAR-RDCN 57/18 |
|
|
| 5.12-9-8 |
JC61-02229A |
BRACKET-GEAR_SCF |
|
|
| 5.12-9-9 |
JC31-00011E |
MOTOR STEP |
|
|
